- Rated Current Range : กพ20 ~ 200[A]
- Frequency Range : 0 ~ 50KHz
Product Features
To be inserted in panel
Multi-holed (2/ 3 holes) product
Convenient for video detection and in
measuring of single-phase/ three-phase
current

Pin Connection

1. VCC[+V]
2. VEE[-V]
3. A-OUT[V]
4. B-OUT[V]
5. C-OUT[V]
6. GND[0V]


  When selecting hall current sensor, choose the external and application circuit specifications first before selecting rated current, output voltage (current) and current sensor power supply to obtain understanding on the types of current sensor more easily. For more details, please contact the Technological Sales Division in our head office.
